Feeler Gauge Sets – Standard US Inch Sizes

US Inch Feeler Gauge Sets

All feeler gage sets feature a metal holder to protect the blades when not in use and consist of many popular styles and sizes. The user can “fan” out the blades for easy selection, and then return the unused gages back into the holder. The screw and lock nut can be tightened to secure the blades in working position. For easy identification, each blade is permanently marked with the blade thickness. All gauges have smooth rounded edges and ends for comfort and safety.

Our steel blades are made of the finest quality high carbon steel that has been hardened and tempered for superior wear resistance. Our stainless steel blades are made of fully hardened and polished 300 series stainless steel noted for its outstanding resistance to corrosion. Both metals provide stable and dependable accuracy. In addition to our US inch Feeler Blade sets, we also have metric feeler gage size sets for your next project.

Contact us for pricing information.

US inch feeler blade
gc-series
Eastern Industries’ professional grade gages. Click on the logo for more information.

Feeler Gauge Sizes – in Inches

Find feeler gauge specifications on our tech spec page in the menu.

Carbon Steel Feeler gauge set in US Inch sizes
FG-26-3 GC SERIES – Carbon Steel Feeler Gauge

This standard carbon steel gage set is perfect for a large variety of applications.

26 blades, 1/2″ wide and 3″ long.

Thickness (in inches) .0015, .002, .0025, .003, .004, .005, .006, .007, .008, .009, .010, .011, .012, .013, .014, .015, .016, .017, .018, .019, .020, .021, .022, .023, .024, .025

tapered feeler gauge set in us inch sizes
FG-26-T-3 GC SERIES – Tapered Feeler Gauge

The blades in this carbon steel set taper from 1/2″ to 1/4″ at the tip for tight applications.

26 blades, 1/2″ wide, tapered to 1/4″ and 3″ long.

Thickness (in inches) .0015, .002, .0025, .003, .004, .005, .006, .007, .008, .009, .010, .011, .012, .013, .014, .015, .016, .017, .018,.019, .020, .021, .022, .023, .024, .025

stepped feeler gage set in us inch sizes
FG-22-STEP GC SERIES – Stepped Feeler Gauge

This carbon steel gage set has blades with .002″ step ground on the tip for Go/No-Go use.

22 blades, 1/2″ wide and 3″ long with .002 deep by 5/8″ step ground at tip.

1/2″ x 12″ long blades.

Thickness (in inches) .004-.006, .005-.007, .006-.008,.007-.009, .008-.010, .009-.011, .010-.012, .011-.013, .012-.014,.013-.015, .014-.016, .015-.017, .016-.018, .017-.019, .018-.020,.019-.021, .020-.022, .021-.023, .022-.024, .023-.025, .024-.026, .025-.027

stainless steel feeler gauge in us inch sizes
FG-25-3-SS XF SERIES – Stainless Steel Feeler Gauge

Every component of this gage set is made of stainless steel for excellent corrosion resistance. The blades are made from full hard 300 series stainless steel for outstanding wear.

25 stainless steel blades, 1/2″ wide and 3″ long.

Thickness (in inches) .0015, .002, .003, .004, .005, .006, .007, .008, .009, .010, .011, .012, .013, .014, .015, .016, .017, .018, .019, .020, .021, .022, .023, .024, .025

Large feeler Gage Set in us inch sizes
FG-35-3 GC SERIES

The larger section of carbon steel blades in this set cover more applications.

35 blades, 1/2″ and 3″ long.

Thickness (in inches) .0015, .002, .003, .004, .005, .006, .007, .008, .009, .010, .011, .012, .013, .014, .015, .016, .017, .018, .019, .020, .021, .025, .026, .027, .028, .029, .030, .031, .032, .033, .034, .035

offest feeler Gage Set in us inch sizes
FG-26-4-45 GC SERIES – Valve Feeler Gauge Set

The offset carbon steel blades in this gage set are bent at 45° to go around impediments.

26 blades, 1/2″ wide, 4″ long with 1″ bent at 45°.

Thickness (in inches) .005, .006, .007, .008, .009, .010, .011,.012, .013, .014, .015, .016, .017, .018, .019, .020, .021, .022, .023, .024, .025, .026, .027, .028, .029, .030

Narrow Feeler Gage Set in us inch sizes
FG-20-Q-6 GC SERIES- Narrow Feeler Gauge Set

This carbon steel feeler gage set has 1/4″ wide feeler blades for narrow applications.

20 blades, 1/4″ wide, 6″ long.

Thickness (in inches) .008, .009, .010, .011, .012, .013, .014,.015, .016, .017, .018, .019, .020, .022, .024, .025, .026, .030, .032,.035

Thick Feeler Gage Set in us inch sizes
FG-26-6 XF SERIES Thick Feeler Gauge Set

Our most versatile set ever. Not too short, not too long, and contains extra thick feeler blades.

With an overall length of 6″, this carbon steel gage set contains the most commonly requested sizes.

Thickness (in inches) .0015, .002, .0025, .003, .004, .005, .006, .007, .008, .009, .010, .011, .012, .013, .014, .015, .016, .018, .020, .022, .024, .026, .028, .030, .040, .060

long feeler gage set in us inch sizes
FG-25-12 GC SERIES – Long Feeler Gauge Set

Longer carbon steel blades in this set of long feeler gauges are a must for difficult to reach applications.

25 blades, 1/2″ and 12″ long.

Thickness (in inches) 0015, .002, .003, .004, .005, .006, .007, .008, .009, .010, .011, .012, .013, .014, .015, .016, .017, .018, .019, .020, .021, .025, .027, .030, .040

long-stainless-steel-feeler-gauge-set-fg-25-12-ss-large in us inch sizes
FG-25-12-SS XF SERIES

This longer length gage set is 100% made of fully hardened, 300 series stainless steel for great wear and excellent corrosion resistance.

25 stainless steel blades, 1/2″ wide and 12″ long.

Thickness (in inches) .0015, .002, .003, .004, .005, .006, .007, .008, .009, .010, .011, .012, .013, .014, .015, .016, .017, .018, .019, .020, .021, .022, .023, .024, .025

extra-long-stainless-steel-feeler-gauge-set-fg-25-24-ss-large in us inch sizes
FG-25-24-SS XF SERIES

This 24″ length gage set is 100% made of fully hardened, 300 series stainless steel for great wear and excellent corrosion resistance.

Commonly used as air gap gages. 25 stainless steel blades, 1/2″ wide and 24″ long.

Thickness (in inches) .0015, .002, .003, .004, .005, .006, .007, .008, .009, .010, .011, .012, .013, .014, .015, .016, .017, .018, .019,.020, .021, .022, .023, .024, .025
